Codemasters EA F1 23 Plugins

[zappadoc]

Codemasters EA F1 23 Plugin Engine 64Bit
by Zappadoc



Simulation/Game:
Name: EA F1 23 game
website: https://www.ea.com/games/f1/f1-23

Plugin Installation/Update:

- Check For Update to get latest plugins and software

- DO NOT FORGET TO ACTIVATE the plugins using the Plugins Manager






EA F1 23 UDP Setup Installation to send telemetry data:

To configure F1 23, simply launch the game and in UDP Telemetery settings



- set Fanatec LED OFF
- set SLI-PRO LED OFF
- set UDP Telemetry to ON
- the rate to 60Hz
- do not activate Broadcast
- if the IP is not set then put 127.0.0.1 which is your local PC IP (localhost)
- Format: 2023

As usual you can use the F1 23 Console Bridge app (the app is inside the software directory) to play with XBOX/PSX version

(First Release - 2023-04-28)

Optional: Select Advanced Options Tab to Overwrite Auto-Setup configuration




[zappadoc]

Plugins updated today (2023-05-31)

Changelog: Conformity with latest UDP specs of F1 23 game

Check for update as usual to update your plugins

[zappadoc]

EA/Codemasters F1 PS4/PS5/XBOX Console Bridge Plugins Available

The �Console Bridge� bridges MotionMax Manager and SLIMax Manager Pro software (the car racing motion simulator manager and usb display devices manager) with your game console Sony PlayStation (PS4/PS5) or Microsoft XBOX.



Check For update to get the latest plugins and applications.

Getting Started With F1 23 Console Bridge

The app F1_2023ConsoleBridge64.exe (inside MotionMax application directory) �bridges� the F1 23 game on PlayStation console to your PC running MotionMax Manager to manage your 6DOF or 2DOF motion simulator.

The PS4 or PS5 console must be power on and be connected to your local network with Ethernet cable.

UDP Telemetry must be activated in game settings
(replace the 127.0.0.1 by the IP of your PC running MotionMax Manager)

� set UDP Telemetry to ON
� do not activate Broadcast.
� Enter the IP address (192.168.x.x) of your PC running MotionMax Manager
� keep the port with 20777,
� set the rate to 60Hz,
� format: 2023
� set audience to: Restricted

Launch MotionMax Manager on the PC and select the default F1 23 game profile (wheel base or gamepad)

Check if the F1_2023ConsoleBridge plugin is ACTIVATED using the Plugins Manager

Start F1_2023ConsoleBridge64.exe on the PC

Now run the F1 23 game on the console and enjoy your motion simulator with your F1 game.

if you intend to use your motion simulator with the addition of SLIMax Manager Pro for VDASH-EMU or USB Display device, you need to configure the SIM Racing Proxy Server (SRPS app is available inside the SLIMax Mgr Pro directory).

Configure the SRPS with:
main UDP port: 20777
forwarding port: 30555 and 30556

Configure the udp port of F1 23 Console Bridge plugin for SLIMax Mgr Pro to 40555
Configure the udp port of F1 23 Console Bridge plugin for MotionMax Manager to 40556





Cheers,
z
