Profiles & Plugin Grouping

1. Overview

OpenSR uses a hierarchical game profile system to manage configurations across:

  • OUT plugins (devices / protocols)
  • IN plugins (games)

This system allows:

  • per-device configuration
  • per-game customization
  • profile sharing across compatible plugins

2. Plugin Identity & Grouping

Each plugin defines its identity via:

GetPluginGroupName(...)

Behavior:

Case 1 — Empty string ("")

  • The system uses:
    • compiled plugin name (without extension)

Example:

rFactor2Plugin.osri → rFactor2Plugin
SLIPROdevicePlugin.osro → SLIPROdevicePlugin

This name becomes:

  • the plugin identifier
  • the profile folder name

Case 2 — Custom group name

  • The provided string is used instead
  • Allows multiple plugins to share:
    • the same profile set

Example use case:

  • Variants of the same game:
    • standard
    • demo
    • AVX version

All can share (example for AMS2, AMS2 Demo and AVX variations):

Automobilista2Plugins

In your plugin header:

void GetPluginGroupName(wchar_t* buffer, size_t bufferSize) const override {
        wcscpy_s(buffer, bufferSize, L"Automobilista2Plugins");
}

3. Profile Folder Structure

All profiles are located under:

<USER-DOCUMENTS>/OpenSR/Profiles/

Structure:

Profiles/
  <OutPluginName>/
    <GamePluginName>/
      profile1.xml
      profile2.xml
      .osr/   (internal host-managed data)

Example:

Profiles/
  SLIPROdevicePlugin/
    rFactor2Plugin/
      default.xml
      custom.xml
      .osr/

4. Mapping Logic

Hierarchy:

OUT Plugin → Game Plugin → Profiles

Meaning:

  • Each OUT plugin has its own configuration space
  • Inside it:
    • configurations are split per game (IN plugin)

Resolution flow:

  1. OUT plugin identifies itself → OutPluginName
  2. IN plugin identifies itself → GamePluginName
  3. Host loads profiles from:
Profiles/<OutPluginName>/<GamePluginName>/

5. Hidden .osr Folder

Each OUT plugin profile directory contains:

.osr/

Managed exclusively by the host

Contains:

  • default profile reference
  • last loaded profile
  • autosetup profile

Autosetup behavior:

  • Automatically loaded when:
    • a game is detected
  • Allows seamless user experience without manual selection

6. Profile Ownership & Access

Host responsibilities:

  • Create profile folders
  • Load and save profiles
  • Manage .osr internal state
  • Handle autosetup logic

Plugin responsibilities:

  • Define:
    • structure (via profile_template.xml)
  • Consume:
    • configuration data provided by the host

7. Profile Sharing

Supported:

Multiple plugins can share the same group name:

  • They will:
    • use the same profile folder
    • access the same configurations

Requirement:

  • Plugins must be fully compatible with shared profiles

8. Lifecycle & Loading Behavior

  • Profiles are:
    • loaded by the host
  • Not directly handled by plugins as files

Typical behavior:

  • Loaded:
    • when game starts
    • when user switches profile
  • Managed dynamically by the dashboard

9. Design Intent

  • Decouple:
    • device configuration (OUT)
    • game telemetry (IN)
  • Allow:
    • reuse across similar plugins
    • scalable configuration system
  • Centralize:
    • profile management in the host
